Full UI

when using the full ui, all management of the alignment is conducted via the image modeling tab there are two options for creating an alignment option 1 registration object marker the registration object marker is an a3 sized chart that can be used for aligning the zero point position the chart in the environment so that it is visible by the witness camera, press f10 to tell the system to align the zero point the zero point will be set to the centre of the chart the floor plane is determined by the angle of the chart, meaning that if the chart is tilted or propped up, then the zero point will align to the chart the chart only needs to be present when setting the zero point, it can be removed following alignment if wished this option is only available when using a mk2 camera bar option 2 manual method this method involves manually selecting a tracking point and then optionally offsetting it's position using a combination of hotkeys it is conducted using the image modeling tab use the cursor (lmb) to select a tracking point in one of the witness camera views, the matching point should be displayed in the opposite view, this should be checked to ensure that the point you are selecting is consistent if they are not then a different point should be selected a ground plane will be displayed when hovering over a tracking point, this will inform the user of both the floor plane and the distance the point is in space, the ground plane guide displays a grid of 1m dimensions once a point is selected then pressing " spacebar " or choosing " set origin " from the ui will snap the zero point to the selected tracking point the zero point can be refined further by using a series of hot keys, the most common of which are z to slide the zero point along the current ground plane alt + x to rotate the zero point around the up axis factors to consider floor plane when the tracking is initialised, the system takes a reading from the accelerometer inside the camera bar to make an estimation of what "up" is, and consequently the ground plane if the camera bar is moving when the tracking is initialised then it is likely the floor plane will be misaligned to aid with visualising this, the ground plane is displayed when hovering the cursor over a tracking point pressing f9 at any point will tell the system to realign the up vector key positions these are pairs of images taken at set intervals as the camera is moved throughout the environment upon starting the tracking, the first pair of key positions is displayed in the image modeling tab by default, it is typically advantageous to scroll through available key positions however to see if there are views more useful to work with offsetting care should be taken when adjusting the zero point, as more and more offsets are applied it becomes increasingly likely that the zero point will become misrepresented in 3d space that is to say it may look correct from the single view that you are adjusting it from, but may be set much closer or further away it is advised to find a tracking point that is close to where you want your zero point to be, as opposed to picking a distant point and applying a large offset observe the zero point from multiple key positions, ideally with some parallax as this will allow you to see if the point is correct in 3d space important hotkeys m go to first key position pair < go to previous key position pair > go to next key position pair ? go to last key position pair f9 realign the up vector using the camera bar gyro f10 align the zero point to the registration marker if it is currently detected alt + x spin zero point around y axis alt + c spin zero point around x axis alt + v spin zero point around z axis
